Kev paub tsom xam ntawm nickel plated busbar kev lag luam

Nickel-plated tooj liab busbar yog cov khoom siv hluav taws xob sib xyaw uas siv high-purity electrolytic tooj liab raws li cov khoom siv hauv paus thiab sib npaug nrog cov hlau npib tsib xee txheej ntawm tooj liab los ntawm cov txheej txheem electrochemical deposition. Cov khoom no yog ib qho tseem ceeb ntawm cov khoom siv hauv kev sib txuas hluav taws xob. Nws muab cov khoom siv hluav taws xob zoo heev ntawm tooj liab nrog lub siab hardness, corrosion kuj thiab tiv thaiv -oxidation nto thaj chaw ntawm npib tsib xee plating. Los ntawm qhov kev xav ntawm cov khoom tsim, Nickel Plated Copper Flat Busbar thiab Flat Bar Liab Ntshiab tooj liab Nickel Plating sawv cev rau feem ntau cov duab plaub hla -section npib tsib xee-plated tooj liab busbar - lub tiaj tus zoo li yooj yim stacked layout thiab multi- txheej thaum uas tig mus kev sib txuas ntawm cov khoom siv hluav taws xob thiab cov khoom sib txuas. Cov liab ntshiab tooj liab puag muaj silvery dawb los yog daj me ntsis tom qab tau plated nrog npib tsib xee. Standard Nickel Plating Flat Busbar npog ntau cov khoom tsim raws li cov qauv kev lag luam loj, thaum Nickel Plated Copper Busbars thiab Nickel Plated Bus Bars feem ntau xa mus rau npib tsib xee{12}}plated tooj liab busbars ntawm ntau yam ntoo khaub lig{13}}sectional shapes (rectangular, L{14}}zoo li tus, Z{12} zoo li tus. Nickel plated Copper Bus Bar yog ib lub npe nrov rau hom khoom no. Nws cov txiaj ntsig tseem ceeb hauv engineering yog nyob rau hauv: ntawm lub hauv paus ntawm kev tswj kom muaj kev ua tau zoo ntawm tooj liab (Ntau dua lossis sib npaug li 98% IACS), npib tsib xee plating daws cov teeb meem ntawm kev yooj yim oxidation ntawm liab qab tooj liab busbars nyob rau hauv ib puag ncig siv, tsis ruaj tsis khov kev tiv thaiv thiab tsis txaus deg hardness. Nws yog dav siv nyob rau hauv kev faib hluav taws xob, lub zog tshiab thiab kev lag luam automation uas muaj cov kev xav tau siab rau kev ntseeg siab thiab ib puag ncig adaptability.

























































Lub hauv paus kev ua tau zoo ntawm nickel-plated tooj liab busbars nyob rau hauv kev xaiv kev tshawb fawb thiab kev sib piv ntawm cov khoom siv tooj liab thiab cov khoom siv nickel plating. Cov khoom siv tooj liab matrix feem ntau yog siab -purity electrolytic tooj liab, nrog lub npe C11000 lossis TU1. Cov ntsiab lus tooj liab ntawm C11000 electrolytic tooj liab tsis tsawg dua 99.90%, thiab cov ntsiab lus oxygen yog tswj ntawm 0.02% thiab 0.05%. Nws muaj cov khoom siv hluav taws xob zoo (Ntau dua lossis sib npaug ntawm 101% IACS, lub xeev annealed) thiab ductility zoo heev, ua rau nws yooj yim rau kev ua haujlwm xws li khoov, xuas nrig ntaus thiab khoov. Rau cov ntawv thov uas xav tau lub zog siab dua, C1100-H semi- nyuaj lossis C10200 oxygen- tooj liab dawb (cov ntsiab lus oxygen tsawg dua lossis sib npaug li 0.002%, haum rau cov txheej txheem vuam rhiab rau hydrogen embrittlement) tuaj yeem xaiv. Lub purity ntawm cov khoom siv ncaj qha cuam tshuam rau qhov zoo ntawm cov plating - cov khoom siv tooj liab nrog cov ntsiab lus tsis huv tuaj yeem tsim cov khoom sib cais thaum lub sij hawm pickling ua ntej plating, ua rau cov pob zeb los yog tsis zoo ntawm cov npib tsib xee plating.



Cov khoom siv nickel plating siv electrolytic npib tsib xee los yog sulfur- muaj nickel ncuav mog qab zib raws li cov khoom siv anode, thiab cov txheej txheem plating feem ntau yog Watt hom (nickel sulfate 300-350g/L, npib tsib xee chloride 40-50g/L,{ boric acid 45g). Lub purity ntawm npib tsib xee plating feem ntau tsis tsawg dua 99.5%, thiab txheej txheej nrog cov yam ntxwv sib txawv tuaj yeem xaiv tau raws li daim ntawv thov: semi-paj nickel plating (sulfur{10}}dawb, zoo ductility, muaj zog corrosion kuj) yog haum rau busbars uas yuav tsum tau khoov thiab tsim; ci npib tsib xee plating (muaj ib tug me me ntawm leej faj, daim iav-ci tsos, siab hardness) yog haum rau pom qhov chaw uas yuav tsum tau cov khoom zoo nkauj; multi-txheej npib tsib xee system ( semi-ci nickel + ci npib tsib xee + microporous npib tsib xee) yog tsim rau huab cua corrosive ib puag ncig.













































































Kev tsim cov nickel-plated tooj liab busbars npog ob theem loj: tooj liab substrate ua thiab kev kho electroplating. Copper substrate ua theem: Ua ntej, siv lub tshuab txiav los yog txiav cov ntaub ntawv raws li daim duab loj, thiab qhov ntev ntev yog tswj tsis pub dhau ± 0.5 hli. Tom qab ntawd nws tau ua tiav los ntawm lub tshuab leveling los xyuas kom meej tias qhov flatness ntawm busbar tsis pub tshaj 1 hli ib 'meter'. Punching (txoj hauj lwm kam rau ua ± 0.2mm) thiab CNC dabtsi yog khoov (khoov vojvoog tsis pub tsawg tshaj 2 npaug ntawm lub thickness ntawm cov tooj liab bar, lub kaum sab xis kam rau ua ± 1 degree) yog ua raws li cov kev cai installation. Tag nrho cov npoo txiav thiab xuas nrig ntaus yuav tsum tau deburred thiab cov npoo chamfered C0.5-C1.0 kom tshem tawm cov kev pheej hmoo ntawm lub kaum ntse ntse tawm. Ua ntej nkag mus rau hauv electroplating, tooj liab substrate yuav tsum tau siv tshuaj degreasing, ntxuav dej kub, pickling activation thiab ntxuav dej ntshiab kom paub meej tias qhov chaw tsis muaj roj stains thiab oxide zaj duab xis.



Nickel electroplating theem: txais yuav Watt- hom nickel plating system (nickel sulfate 300-350g/L, npib tsib xee chloride 40-50g/L, boric acid 35-45g/L). Qhov kub ntawm cov tshuaj plating yog tswj ntawm 50-60 degree, thiab pH tus nqi yog tswj ntawm 3.8-4.2. Lub cathode tam sim no ceev yog 2-5A / dm², thiab tus nqi deposition yog kwv yees li 0.2-0.3μm / feeb. Cua agitation txuas ntxiv thaum lub sij hawm electroplating txheej txheem los xyuas kom meej uniformity ntawm txheej. Cov txheej tuab tuaj yeem xaiv tau nyob rau hauv thaj tsam ntawm 3-25μm raws li daim ntawv thov, 5-8μm rau cov chaw nyob sab hauv tsev, thiab 12-15μm rau sab nraum zoov lossis corrosive ib puag ncig. Tom qab plating, lub workpiece undergoes peb-theem countercurrent dej ntxuav, dej kub ntxuav thiab cua kub kom qhuav, thiab yog passivated mus ntxiv txhim kho corrosion kuj. Kev soj ntsuam zoo: Txhua pawg ntawm cov khoom raug kuaj pom (100% kev soj ntsuam pom, tsis muaj tev, tsis muaj npuas, tsis muaj scorching), thickness tshuaj xyuas (X-ray fluorescence thickness gauge, tsis pub tsawg tshaj 5 qauv ib batch), kev soj ntsuam xyuas lub zog (saib seb lub txheej yog tev tawm tom qab bending los yog 1 9 degree) cov neeg siv khoom xav tau).



















.

























































Copper busbars muaj cov khoom siv hluav taws xob zoo heev hauv kev faib hluav taws xob thiab hluav taws xob sib txuas hluav taws xob (kev coj ua tau ncav cuag ntau dua 98% IACS) thiab yog cov khoom siv zoo tshaj plaws rau kev nqa cov dej loj. Txawm li cas los xij, liab qab tooj liab busbars ntsib peb qhov teeb meem engineering hauv qhov chaw siv tiag tiag. Ua ntej, tooj liab yog yooj yim oxidized nyob rau hauv atmospheric ib puag ncig. Nyob rau hauv ib txwm kub thiab av noo tej yam kev mob, cuprous oxide (Cu₂O) thiab tooj liab oxide (CuO) yuav raug tsim rau ntawm tooj liab. Ob lub oxides no muaj cov hluav taws xob tsis zoo, thiab lawv qhov kev tiv thaiv yog ntau qhov kev txiav txim siab ntau dua li ntawm cov hlau tooj liab. Raws li lub sijhawm ua haujlwm dhau los, cov oxide txheej maj mam thickens, ua rau kev sib cuag ntawm lub busbar overlap nto mus txuas ntxiv, ua rau hauv zos overheating. Nyob rau hauv cov xwm txheej hnyav, nws yuav ua rau qhov chaw sib txuas raug hluav taws xob lossis hluav taws xob hluav taws xob. Qhov thib ob, lub hardness ntawm tooj liab yog tsawg (lub annealed hardness ntawm ntshiab tooj liab yog hais txog 40-60 HV). Thaum bolted kev sib txuas tau ua, qhov chaw sib cuag yog qhov yooj yim rau nkag los yog indentation deformation nyob rau hauv siab. Qhov kev deformation no yuav txo qhov kev ua tau zoo ntawm qhov chaw sib cuag thiab ua rau qhov kev sib cuag tsis zoo ntxiv. Tshwj xeeb tshaj yog nyob rau hauv lub voj voog siab tam sim no, cov thermal expansion thiab contraction cuam tshuam yuav ua kom cov txheej txheem degradation. Thib peb, nyob rau hauv qee qhov chaw tshwj xeeb (xws li cov tshuaj tsuag ntsev ntawm ntug dej hiav txwv, thaj chaw muaj kuab paug, muaj peev xwm electrolyte to hauv lub roj teeb), tooj liab kuj yuav raug corroded los ntawm chloride ions los yog sulfides, ua patina los yog tooj liab sulfide corrosion khoom.



Nickel plating yog kev paub daws teeb meem engineering los daws cov teeb meem saum toj no. Nickel plating forms a dense physical barrier on the copper surface - nickel itself has a high standard electrode potential and has a strong tendency to passivate in the atmospheric environment. Ib qho nyias nyias (li 1-2nm) thiab ntom nickel oxide passivation zaj duab xis yuav sai sai rau saum npoo. Cov zaj duab xis passivation no tuaj yeem raug crushed nyob rau hauv kev sib cuag siab los tsim hlau conduction thiab yuav tsis txuas ntxiv thicken lub sij hawm xws li tooj liab oxide zaj duab xis. Raws li qhov tshwm sim, Nickel-Plated Copper Flat Bus Bar tuav ruaj khov tsis muaj kev tiv thaiv nyob rau lub sijhawm ua haujlwm ntev. Nyob rau tib lub sijhawm, lub hardness ntawm npib tsib xee txheej (150-300 HV) yog siab dua li ntawm tooj liab matrix. Qhov saum npoo ntawm txheej yog tsis yooj yim rau indentation deformation thaum bolt txuas. Txawm tias nyob rau hauv ntau yam disassembly thiab sib dhos los yog kev co, lub siab tis ntawm qhov chaw sib cuag tuaj yeem nyob ruaj khov. Tsis tas li ntawd, npib tsib xee plating muaj kev ua siab ntev rau cov tshuaj chloride ions, sulfides thiab tsis muaj zog acid ib puag ncig, ua cov nickel-plated tooj liab busbars muaj kev nyab xeeb siv nyob rau hauv corrosive ib puag ncig xws li ships, offshore platforms, lub zog cia roj teeb packs thiab industrial electroplating rhiav. Nyob rau hauv cov ntsiab lus, npib tsib xee plating yog ib qho zoo tshaj plaws engineering kev coj ua los txhim kho oxidation tsis kam, tiv tauj stability thiab ib puag ncig adaptability ntawm busbars yam tsis muaj kev txi cov khoom ntawm tooj liab.















































































Yog tias koj xav tau kho qhov corrosion heev -resistantNickel{0}}Plated Bus Barrau koj lub siab -voltage switchgear lossis lub zog cia, peb pab neeg muaj peev xwm muab cov ncauj lus kom ntxaws plating thickness soj ntsuam cov ntaub ntawv thiab cov ntsev tsuag tshuaj ntsuam xyuas cov ntaub ntawv kom paub meej tias cov khoom ua tau raws li koj qhov kev tsim qauv engineering thiab ntev - lub sijhawm ua haujlwm.
